Features

Name: Custom-made Square Shape Lighting Lifter

ZH-DWD18TE This multi-functional lifting system is designed to solve the maintenance problem of high attitude electrical equipment, such as lighting, CCTV, smoke detector, banner etc.
▍Advantages ▍

1. Cost saving: personnel expenses, mantainance equipment rental costs, energy costs.
2. Safty: Decrease the risk of people getting electric shock or fallen from high attitude.
3. Multi-functional: Remote control, Wire group control box (maximum 99 sets lifters can be controlled by one box), Customization modules (special moduel and specification as per client’s requirements).
4. Efficiency: decreases maintenance time, simplify routine inspection.


▍Application scenario ▍

Industry: warehouse lighting system, metro & rail station lighting system, oil & gas factory lighting system
Commercial: Gymnasium lighting system, Hotel lobby lighting & CCTV, smoke detector, Shopping mall lighitng & CCTV


▍Features ▍

1. Large scope of application: ZH-DWD18TE is the most popular model among the clients, the loading capacity from 8kgs to 13kgs, loading height from 10 meters to 35 meters, it has large scope of application range.
2. Double wires self-locking system: With Zhenhong’s patented technology, in case of wire broken, the self-locking system can ensure the hanging object won’t fall down, which can reduce the risk of incident.
3. Strong pulling force: 1.8mm diameter steel wire rope that provides 300KGS pulling force.
4. Optional control system: wirless romote controller/ wire control box.

▍Specification ▍

Product Size 22.5*22.5*42cm
Net Weight 4.8kgs
Maximum Lifting Capacity 13kgs
Voltage Input 220V/120V 50/60Hz
Rated Power Input 25W
Protection Against Electric Shock  CLASSⅠ
Protection Class IP55
Maximum Matching Lighting Voltage 800W
Remote Control Distance ≤50m
Steel Wire Rope Diamter 1.8mm(aviation grade)
Lifting Height ≤35m
Lifting Speed 4.0m/min
